No. The sleeve goes on the output. Then you put an up sized union over that.
Plumbing an Abyzz 200
- Thread starter revhtree
- Start date
- Tagged users None
OP
OP
revhtree
Owner Administrator
Staff member
Super Moderator
Reef Squad
Partner Member 2024
Excellence Award
RGB
Photo of the Month
Article Contributor
R2R TV Featured
Hospitality Award
Article Administrator
Black Friday Sponsor
Industry Professional
My Tank Thread
My Aquarium Showcase
- Joined
- May 8, 2006
- Messages
- 49,235
- Reaction score
- 98,071
- Seller Rating
- 4 ★
- Rating Count
Oh that's gonna be big! Ha!
- Joined
- Mar 14, 2010
- Messages
- 1,838
- Reaction score
- 3,482
- Location
- Gilroy, CA
- What state or country do you live in
- California
I know how Michael from the office would respond to that!
If you could go 1.5" all the way to the tank it would be great. Heck the best is 2". Then you put a 2" wye or tee, reduce to 1", and the. Have that go directly into the tank or through a sea swirl. No locline. That would get you maximum flow potential. The smaller the pipe and the more fittings, the less flow. Now with the Abyzz it is less noticeable because they do well against head pressure. Still, go big.
If you could go 1.5" all the way to the tank it would be great. Heck the best is 2". Then you put a 2" wye or tee, reduce to 1", and the. Have that go directly into the tank or through a sea swirl. No locline. That would get you maximum flow potential. The smaller the pipe and the more fittings, the less flow. Now with the Abyzz it is less noticeable because they do well against head pressure. Still, go big.
When it comes to tank plumbing GO BiG, especially the return lines. Larger ID PVC/hoses let the water travel slower and reduces drag (head pressure lose). Going larger on a drain line can help prevent clogs but too large and could create noise.
OP
OP
revhtree
Owner Administrator
Staff member
Super Moderator
Reef Squad
Partner Member 2024
Excellence Award
RGB
Photo of the Month
Article Contributor
R2R TV Featured
Hospitality Award
Article Administrator
Black Friday Sponsor
Industry Professional
My Tank Thread
My Aquarium Showcase
- Joined
- May 8, 2006
- Messages
- 49,235
- Reaction score
- 98,071
- Seller Rating
- 4 ★
- Rating Count
Got the pump plumbed into my plumbing that was already there. I will be taking time in the next few weeks to redo the plumbing and go with bigger PVC.
You live and hopefully you learn!
You live and hopefully you learn!
OP
OP
revhtree
Owner Administrator
Staff member
Super Moderator
Reef Squad
Partner Member 2024
Excellence Award
RGB
Photo of the Month
Article Contributor
R2R TV Featured
Hospitality Award
Article Administrator
Black Friday Sponsor
Industry Professional
My Tank Thread
My Aquarium Showcase
- Joined
- May 8, 2006
- Messages
- 49,235
- Reaction score
- 98,071
- Seller Rating
- 4 ★
- Rating Count
One thing about these pumps is they can be loud as the bearings break in. Mine was pretty loud day one. But today it's almost silent.
PedroYoung
Valuable Member
Here in the U.S. the distributor supplies Metric to US fittings that you use a PVC to ABS "transition cement", then standard PVC glue from there. If you are using straight PVC fittings you need to use the ABS to PVC cement for that fitting.
PedroYoung
Valuable Member
Here is what we use in the states.
https://www.ebarnett.com/Sku/356183...MIho2VlbKP1wIVDyhpCh1U2wGVEAQYASABEgJlqfD_BwE
PedroYoung
Valuable Member
Rev, any chance you could post a pic of the plumbing on your Abyzz A200 to update this thread? I'm about to get into plumbing mine and I'm feeling just like you did when you started this post. I have the same adapters, but unsure exactly how to get it all together.
PedroYoung
Valuable Member
I'll chime in since I'm still waiting on the response from 11/2017 with what I'm doing. Not sure what the pumps are shipping with now, but when I got mine they came with 2 grey adapters (see Revh's earlier post). After some fumbling around I realized how to use them. They slip OVER the metric connections on the inlet/outlet like this..
Untitled by Peter Young, on Flickrtop view
Untitled by Peter Young, on Flickrthat adapter has the same OD as 1.5" PVC (or 2" on the inlet) so you put a union over that piece like this......
Untitled by Peter Young, on FlickrThen you can plumb however you'd like. I'm doing submersible so I went with 1.5" barbed fitting....
Untitled by Peter Young, on FlickrSo that I can use the very difficult to find and ridiculously expensive thick walled silicone tubing to the sump bulkhead...
Untitled by Peter Young, on FlickrHere is a picture showing the 2" inlet adapter
Untitled by Peter Young, on FlickrPlease note these are all dry fitted right now, I'm still in the (lengthy) process of getting fully plumbed. Abyzz was recommending using a ABS to PVC transition cement rather than straight PVC glue since the body is ABS but I haven't progressed to that stage yet. Let me know how it goes with yours.
EDIT: Not sure what's up with the rotated pics, I've never had that happen before and I've posted many pics. Hopefully you'll still get the idea.
GoVols
Cobb / Webb - 1989
Reef Squad Leader
Excellence Award
Reef Tank 365
MTRCMember
Article Contributor
Hospitality Award
R2R Research
My Tank Thread
@revhtree
Great thread, my freind
But, I've got the A100 and plumbed to the below link.
www.reef2reef.com
Just passing it along
Great thread, my freind
But, I've got the A100 and plumbed to the below link.
Abyzz A100 Plumbing / Guidance
Well hope this thread helps someone down the line: Pretty much had to figure out on my own: The Abyzz A100 comes with an adapter ring, to go on the pump's output. That adapter ring, fits an 1" slip union. Used the Oatey ABS to PVC cement Cemented on the adapter ring: Went 1" slip union /...
www.reef2reef.com
Just passing it along
Zbryant
Active Member
- Joined
- Nov 23, 2017
- Messages
- 192
- Reaction score
- 117
- What state or country do you live in
- Maryland
I'll chime in since I'm still waiting on the response from 11/2017 with what I'm doing. Not sure what the pumps are shipping with now, but when I got mine they came with 2 grey adapters (see Revh's earlier post). After some fumbling around I realized how to use them. They slip OVER the metric connections on the inlet/outlet like this..
top view
that adapter has the same OD as 1.5" PVC (or 2" on the inlet) so you put a union over that piece like this......
Then you can plumb however you'd like. I'm doing submersible so I went with 1.5" barbed fitting....
So that I can use the very difficult to find and ridiculously expensive thick walled silicone tubing to the sump bulkhead...
Here is a picture showing the 2" inlet adapter
Please note these are all dry fitted right now, I'm still in the (lengthy) process of getting fully plumbed. Abyzz was recommending using a ABS to PVC transition cement rather than straight PVC glue since the body is ABS but I haven't progressed to that stage yet. Let me know how it goes with yours.
EDIT: Not sure what's up with the rotated pics, I've never had that happen before and I've posted many pics. Hopefully you'll still get the idea.
where did you find the “very difficult to find and ridiculously expensive thick walled silicone tubing”? Is it 1.5 inch?
PedroYoung
Valuable Member
Yes, it's 1.5". I got it from Abyzz via Coralvue. Had to buy 1 meter, only needed about 8".
